High Resolution Stainless Steel Platforms PL.150.HRP.EX.H for Hazardous Areas – Radwag Industrial Weighing Solutions

51,811.12 RON

61,655.23 RON (VAT included)
High Resolution Platforms PL.150.HRP.EX.H – Radwag – Laboratory and Industrial Weighing Solutions

Available on backorder

Radwag

High Resolution Stainless Steel Platforms PL.150.HRP.EX.H for Hazardous Areas – Radwag Industrial Weighing Solutions

Stainless Steel HRP EX.H Platform Wherever high readability and precision are important. Wherever good repeatability in harsh industrial conditions matters. Stainless Steel HRP EX.H Platforms are the ideal solution for any type of industry.

Repeatability that cannot be repeated by others

Stainless Steel HRP EX.H Platforms have a built-in internal adjustment system. Automatic internal adjustment guarantees the best quality of work and repeatability of results. You save time and avoid the inconvenience of manual adjustment.

Hazardous areas are their natural environment

Stainless Steel HRP EX.H Platforms have been developed in accordance with Directive 2014/34/EU and the IECEx scheme and, depending on their design, can operate in environments containing explosive gases or dust, classified as zones: 2 and 22. We have equipped them with an intrinsically safe RS 485 communication interface, which allows the platform to work with the PUE HX5.EX weighing meter.

To power the platforms, we have dedicated intrinsically safe PM02.EX-1-2 or PM02.EX-2-2 power supplies. Use the potential Stainless Steel HRP EX.H Platforms work with the PUE HX5.EX weighing terminal and are compatible with RADWAG receipt printers. In addition, you will match them with appropriate antivibration tables from our offer, and thus increase the readability of your measurements. The use of stainless steel for the construction of the pan guarantees you a long life of the platform. Fearless of its contact with moist objects or accidental splashing. Check the price in our store Buying from the producer is all about the pros Update as standard You always get the latest version of the device and software. We are constantly improving our products. This is priceless Technical support from the product developers. Who better to know the answers to your questions? Smaller carbon footprint A solidly packaged shipment travels only one way – the one to you. Long life for your balance In our permanent offer you will find accessories for our balances and scales, such as cables, weighing pans and power supplies, as well as all spare parts. And we carry out legalization and periodic inspections in our laboratory. The important thing You buy a product developed and manufactured in Europe – you get a device with a certain standard of compliance.


Metrological parameters
Maximum capacity [Max] 150 kg
Preload range 30 kg
Readability [d] 1 g
Tare range -150 kg
Repeatability 1.5 g
Linearity ±3 g
Adjustment internal (automatic)
Construction
Protection class IP 66/67
Construction Stainless steel AISI304
Weighing pan material Stainless steel AISI304
ATEX Certification
ll 3G Ex ic IIC T4 Gc
ll 3D Ex ic IIIC T60ºC Dc
IECEx Certification
Ex ic IIC T4 Gc
Ex ic IIIC T60ºC Dc
Communication interface
Communication interface RS485
Electrical parameters
Power supply 100 – 240 V AC 50/60 Hz
Environmental conditions
Operating temperature +10 — +40 °C
Relative humidity 15% — 80%
Physical parameters
Weighing pan dimensions 500×400 mm
Packaging dimensions 1000×800×307 mm
Net weight 71.5 kg
Gross weight 119 kg
