Digital Force Gauges – SADFG
Digital Force Gauges – SADFG
Our digital portable dynamometers can measure the force weight , both in traction, both in compression , in threedifferent scales : N, Kg , e lb.
The instruments, retrofitted to operate on stators, are equipped with a full set of accessories easy to install ( flathead adapter, onical, chisel, hook, extension) RS232 interface very intuitive and a resistant case where they can be stored and transported.
Similar
Analogyc force gauges N/Kg
Accessories
Standard Supply:
- Main unit
- Compression and traction adapters
- Extension rod
- Cable and software
- Carrying case
- User’s manual
-
Handle
-
Push disk
-
Push and pull attachment
-
Clamps
-
Test stand
-
Calibration report
Main areas of use and application:
|
Agriculture |
Stadium of fruit ripening |
|
Food Industry |
Consistency, bottles opening load, packaging testing |
|
Textile Industry |
Fabrics resistance |
|
Leatherwear |
Resistance of bags, soles etc . |
|
Carpentry |
Resistance of packages |
|
Paper industry |
Resistance of paper, cardboard and packaging |
|
Chemical industry |
Adhesion of coatings, gels, opening loads of bottles |
|
Rubber & Plastics |
Parts strength , fiber assemblies, films, rubbers, foams, etc. |
|
Glass and ceramics |
Testson Packaging |
|
Metallurgy |
Material resistance |
|
Cutlery |
Mechanical strength and efforts needed to handle them |
|
Machinery |
Parts resistance and assembly, flow, breaking load |
|
Automotive |
Shock absorbers test and effort needed related to mechanisms |
|
Springs |
Compression, tension, torsion |
|
Cosmetics |
Granularity, cosmetic bag opening and closing |
|
Medical industry |
Load in physical therapy, syringes resistance, capsules hardness |
|
metrology |
Sensor calibration, compression, torsion, tension |
|
Electronic engineering |
Capacity, load to screw /unscrew, load buttons, |
|
Packagingindustry |
Opening,breaking, untaploading, film drilling |
Essential range of accessories in order to maximize your force gauge. Suggested to be employed in synergy with internal load cell force gauges and related test stands. Non standard clamps available on demand.
Data Sheet
|
Model |
SADFG 0002 |
SADFG 0005 |
SADFG 0010 |
SADFG 0020 |
SADFG 0050 |
SADFG 0100 |
SADFG 0200 |
SADFG 0500 |
SADFG 1000 |
|
Standard |
ISO 376 ; ASTM E 74 |
||||||||
|
Load cell |
Integrated |
||||||||
|
Capacity |
2 N 0,2 Kg |
5 N 0,5 Kg |
10 N 1 Kg |
20 N 2 Kg |
50 N 5 Kg |
100 N 10 Kg |
200 N 20 Kg |
500 N 50 Kg |
1.000 N 100 Kg |
|
Resolution |
0,001 N |
0,001 N |
0,01 N |
0,01 N |
0,01 N |
0,1 N |
0,1 N |
0,1 N |
1 N |
|
Min. load |
1% F.S. |
||||||||
|
Accuracy |
± 0,5% F.S. |
||||||||
|
Measuring units |
N ; Kg ; Lb |
||||||||
|
Functions |
Track ; Peak ; Auto-peak ; PreSet ( max/min ) |
||||||||
|
Display reading sense |
Reversible |
||||||||
|
Memory |
√ ( max, min, average function ) |
||||||||
|
Data output |
√ |
||||||||
|
Auto switch-off |
√ |
||||||||
|
Power supply |
Rechargeable battery |
||||||||
|
Dimensions |
230 x 66 x 37 mm |
||||||||
|
Weight |
300 g |
||||||||
(*) note: The data acquisition PC is only possible if the measurements are carried connected in "real-time" to the terminal
