Analog shore hardness testers A, D, E – SA6410
Analog shore hardness testers – SA6410
To measure hardness of a material the ideal instrument is the hardness tester. The durometer must be pressed on the material to analyze by entering the sensor (it will leave a small mark called “Deposal”) at this point will be possible to read on the quadrant the hardness value detected in the material, nothing simpler,immediateand functional.
Hardness tester always leave a mark, so it must be used in area where the deposal doesn’t bother or on appropriate sample of the same test material.
Features:
Small size, high quality materials make this instrument ideal for laboratory and field use.
The hardness tester is a measurement instrument used to measure materials hardness. Each type of hardness tester refers to a specific scale of values, for this instrument is the “Shore scale” (A,E,D) and it’s values range is 0-100H.
Shore A: Used to measure the hardness for softer materials such as rubber, elastomers, and other rubbery materials like neoprene, silicone and vinyl. It can also be used for soft plastic, felt, leather and similar materials..
Shore D: Used to measure harder material compared to the A scale such as plastics, formica, epoxides and plexiglass.
|
Model |
SA6410A |
SA6410D |
|
Standard |
ISO 868 ; ISO 48-4 ; ISO 48-7; ASTM D 2240 |
|
|
Scales type |
A |
D |
|
Indicative applications |
Neoprene, common rubber, soft pvc, elastomers, leather, etc. |
Formica, plexiglass,hard plastic, plastic fibers, polyethylene etc. |
|
Display range |
0 ~ 100 HS |
|
|
Accuracy |
± 1 HS |
|
|
Resolution |
1 HS |
|
|
Peak hold |
√ |
|
|
Dimensions |
115 x 60 x 25 mm |
|
|
Weight |
0,5 Kg |
|
