Compact Photometer PF-3 in Case
The compact photometer PF-3 covers the important soil parameters like ammonium, potassium, nitrate and phosphate. Together with VISOCOLOR ® ECO tests and a suitable sample preparation for soil extraction, the PF3 allows a quick view on the nutrient content of the soil.
- Power supply with batteries or rechargeable batteries
- Results in different units
- Add new tests and parameters anytime
- Power supply and data transfer via USB port
- Free of charge data export software
Technical data:
- Type: LED-Photometer with 3 Interference filters
- Wavelengths: 365 nm, 450 nm, 660 nm
- Accuracy: ± 2 nm, bandwidth at half transmission 10-12 nm
- Cuvette slot: round cuvettes 16 mm AD
- Measuring modes: pre-programmed MN tests VISOCOLOR / NANOCOLOR
- Memory: 50 results
- Housing: water proof according to IP 68
- Dimensions: 170 × 95 × 68 mm
Delivery contents:
- photometer PF3
- VISOCOLOR ECO Tests for: Nitrate, Potassium, Ammonium, Phosphate, pH,
- accessories for sample preparation
- pH test sticks 0 – 9
- manual
- batteries
- case
Evaluation of the convenient NANOCOLOR® tests is also possible.
Item-No.: 20100 – Compact Photometer PF-3 in Case
Ordering information consumables:
VISOCOLOR ECO Tests
- 20101 – Ammonium 3 (0.1 -2.0 mg/l NH4-N), 50 tests
- 20102 – Potassium (2 – 15 mg/l K+), 60 tests
- 20103 – Nitrate (4 – 60 mg/l NO3 -), 100 tests
- 20104 – Phosphate (0.2 – 5.0 mg/l PO4-P), 80 tests
NANOCOLOR Tests, 20 tests each
- 20131 – Ammonium 10 (0.2 – 7.0 mg/l NH4-N)
- 20132 – Ammonium 50 (1.0 – 40.0 mg/l NH4-N)
- 20133 – Potassium 50 (2-50 mg/l K+)
- 20134 – Nitrate 50 (2 – 100 mg/l NO3 -)
- 20135 – Phosphate 5 (0.20 – 5.00 mg/l PO4-P)
- 20136 – Phosphate 15 (0.3 – 15.0 mg/l PO4-P)
